Jefferson Tundra 16mm 50 Tonne Low Height Hydraulic Cylinder

Jefferson Tundra 16mm 50 Tonne Low Height Hydraulic Cylinder

TUNHYDCY50-16L
£379.99

Extremely compact cylinders that are designed for general lifting and positioning job where high power, low height and portability are required. Compatible with all of the Tundra Hydraulic Hand Pumps. Suitable for Industrial environments. Fitted with stopping ring, this protects the cylinder when the piston comes to a stop because it absorbs the weight from the other side. Chrome plated cylinder wall and primary piston to prevent corrosion and reduce friction. Spring loaded piston which allows for quick release. Tundra® Hydraulic Cylinders provide a reliable device for safely lifting large structures.

  • Specifications
  • Tonnage capacity: 50 Tonne
  • Stroke: 16mm
  • Min oil required: 101cm3
  • Closed height: 72mm
  • Extended Height: 88mm
  • Length x Width: 148 x 120mm
  • Inside diameter: 95mm
  • Piston rod diameter: 70mm
  • Weight: 7.8kg
